Overload protection interface cable between Shimpo FGV force gauges and FGS-100E / FGS-220VC stands

Shimpo FGS-100ECBL interface cable that transmits the overload signal from the FGV force gauge to the FGS-100E and FGS-220VC motorised stands.

Compatible with

• FGS-100E-H – Vertical motorised test stand Shimpo FGS-100E-H, high speed 20–600 mm/min, capacity 50 kg
• FGS-100E-L – Vertical motorised test stand Shimpo FGS-100E-L, low speed 6–180 mm/min, capacity 50 kg
• FGS-220VC – Vertical motorised test stand Shimpo FGS-220VC with software, capacity 100 kg
• FGV-10XY – Digital force gauge with memory and data outputs Shimpo FGV-10XY, capacity 10 lb (5 kg, 50 N)
• FGV-100XY – Digital force gauge with memory and data outputs Shimpo FGV-100XY, capacity 100 lb (50 kg, 500 N)
• FGV-20XY – Digital force gauge with memory and data outputs Shimpo FGV-20XY, capacity 20 lb (10 kg, 100 N)
• FGV-0.5XY – Digital force gauge with memory and data outputs Shimpo FGV-0.5XY, capacity 0.5 lb (200 g, 2 N)
• FGV-50XY – Digital force gauge with memory and data outputs Shimpo FGV-50XY, capacity 50 lb (20 kg, 200 N)
• FGV-5XY – Digital force gauge with memory and data outputs Shimpo FGV-5XY, capacity 5 lb (2 kg, 20 N)
• FGV-2XY – Digital force gauge with memory and data outputs Shimpo FGV-2XY, capacity 2 lb (1000 g, 10 N)
• FGV-1XY – Digital force gauge with memory and data outputs Shimpo FGV-1XY, capacity 1 lb (500 g, 5 N)
• FGV-200XY – Digital force gauge with memory and data outputs Shimpo FGV-200XY, capacity 200 lb (100 kg, 1000 N)

Documentation

• Catalogue: fgs 100e cat24 rev1

Price and availability

Models without a listed price are offered with a configuration defined together with our technical support: contact us for a quote stating your application and measuring range.
